Dual color beam splitter
product description
Base material: Fused quartz, K9 glass
Face shape：:<λ/10 @ 632.8nm
Degree of finish：40-20
Chamfer：0.5mm, 45°
Coating：Electron beam deposition multilayer dielectric coating
Angle of incidence：0°,45°
Clear aperture :> 85% diameter
laser-damaged threshold ：:>5J/cm2(1.06μm,1ns)
Applications :
Product Advantage :
Product Parameters :
|
angle of incidence |
Transmission wavelength(nm) |
transmissivity |
reflection wavelength(nm) |
reflectivity |
|
0° |
808 |
>90% |
946 |
>99.5% |
|
0° |
808 |
>90% |
1064 |
>99.5% |
|
0° |
808 |
>90% |
1320 |
>99.5% |
|
0° |
940 |
>90% |
1030 |
>99.5% |
