Single wavelength antireflection coating
product description
Single wavelength antireflection coating
Base material: Fused quartz, K9 glass
Face shape：:<λ/10 @ 632.8nm
Degree of finish：40-20
Chamfer：0.5mm, 45°
Coating：Electron beam deposition multilayer dielectric film（coating）
Angle of incidence：0°
Clear aperture :> 85% diameter
Applications :
Product Advantage :
Product Parameters :
|
wavelength(nm) |
residual reflectance |
|
193 |
<0.5% |
|
284 |
<0.5% |
|
355 |
<0.2% |
|
632.8 |
<0.2% |
|
670 |
<0.2% |
|
780 |
<0.2% |
|
808 |
<0.2% |
|
980 |
<0.2% |
|
1030 |
<0.2% |
|
1053 |
<0.2% |
|
1064 |
<0.2% |
|
1310 |
<0.15% |
|
1550 |
<0.15% |
